Vacuum Packing Machine SV-500 - Ital Form

The Ital Form SV-500 commercial free standing chamber vacuum packing machine delivers increased capacity and performance for meat processing facilities, butcher shops, seafood suppliers, and high-volume commercial kitchens. Driven by a dependable 20 m³/h vacuum pump powered by a 1.2 kW motor, this unit consistently creates high-level vacuum seals to protect food against oxidation, dehydration, and moisture loss.

A primary advantage of the SV-500 is its extended 500 mm sealing bar with a 10 mm seal width, which accommodates wide vacuum pouches or allows for sealing multiple smaller packages simultaneously in a single cycle. The spacious internal chamber, measuring 530 x 530 x 75 mm, comfortably holds larger primal cuts of fresh meat, whole cured meats, and large cheese blocks. Built on a heavy-duty free standing frame weighing 105 kg with external dimensions of 585 x 650 x 980 mm, it operates on a standard single-phase 220V 50-60Hz power supply for dependable everyday production.

Technical Specifications:

• Manufacturer: Ital Form
• Model: SV-500
• Device Type: Free standing chamber vacuum packing machine
• Pump Capacity: 20 m³/h
• Pump Power: 1.2 kW
• Sealing Length & Width: 500 x 10 mm
• Chamber Dimensions (LxWxH): 530 x 530 x 75 mm
• Overall Dimensions (LxWxH): 585 x 650 x 980 mm
• Power Supply: 220 V / 50-60 Hz
• Net Weight: 105 kg
• Application: Meat processing plants, butcher shops, cheese producers, seafood suppliers, catering centers
